Item description

MQ-135 เป็นเซนเซอร์ตรวจวัดแก๊สที่เป็นพิษต่อมนุษย์เช่น แก๊สแอมโมเนีย แก๊สซัลไฟด์ เบนซีน รวมไปถึงควันและแก๊สพิษ



Operating principle:

MQ-135 gas sensor applies SnO2 which has a lower conductivity in the clear air as a gas-sensing material. In an atmosphere where there may be polluting gas, the conductivity of the gas sensor raises along with the concentration of the polluting gas increases. MQ-135 performs a good detection to smoke and other harmful gas, especially sensitive to ammonia, sulfide and benzene steam. Its ability to detect various harmful gas and lower cost make MQ-135 an ideal choice of different applications of gas detection.

MQ-135 Sensor Features

  • Wide detecting scope
  • Fast response and High sensitivity
  • Stable and long life
  • Operating Voltage is +5V
  • Detect/Measure NH3, NOx, alcohol, Benzene, smoke, CO2, etc.
  • Analog output voltage: 0V to 5V
  • Digital output voltage: 0V or 5V (TTL Logic)
  • Preheat duration 20 seconds
  • Can be used as a Digital or analog sensor
  • The Sensitivity of Digital pin can be varied using the potentiometer
